Sony FX6 Top Plate MK II Single

Add even more functionality to your Sony FX6 camera with the Sony FX6 Top Plate MK II Single. This top plate attaches to the top of the camera, wrapping around the top handle, providing secure mounting points for a wide range of accessories. Integrated NATO rails run the length of the plate, with spring-loaded safety releases on both ends and mounting points for lens adaptor supports. With all these added features, you’ll be able to get even more out of your Sony FX6 camera.

Features

• Features 6x 3/8”, 4x 1/4” points and 2x Quick Detach (QD) sockets

• Integrated NATO rails with safety releases on both ends

• Mounting points for lens adaptor supports

• Lightweight and low profile with helicoils for durability

• Mounts around Sony FX6 top handle with option to use Filler Piece for middle section

• Relocating point for clips to maintain cable management

Helicoil, Nato, and QD

Any rigging solution is possible with the Top Plate. With threaded, NATO, and QD points, you can easily change your rig configuration to match your needs. The stainless-steel helicoiled fittings provide added strength and prevent threads from stripping or binding. Quick Detach (QD) sockets provide a rapid way to connect & disconnect straps and anchors, for extra peace of mind in fast paced situations.

Lens adaptor support

When using the Sony FX6 with large PL mount lenses, adapter supports can be secured using the two M5 mounting points at the front of the top plate. The solid connection ensures that your lens adaptor stays firmly in place, eliminating any chance of flex or play.

Compatible with

The Top Plate can also be used with B4004.1006 Filler piece to add a third NATO rail in the middle which provides a centered mounting point. Useful for gimbal builds & other setups where the FX6 handle is not required.

No compromises

Made from the highest quality materials, the Sony FX6 Top Plate Mk II is built to last, offering years of reliable use.

Specifications

Compatibility: Sony FX 6

Mounting:

Top: 2 x NATO Rails

Top: 6 x 3/8"-16 Female

Top: 4 x 1/4"-20 Female

Top: 2 x Quick Detach (QD)

Front: 2 x M5 Female

Dimensions: 5.7 x 3.4 x 0.7" / 14.5 x 8.7 x 1.9 cm

Weight: 4.6 oz / 129 g
